PDE132
ahd@cisanet.com
www.cisa.com
background image
b
r
o
n
z e
g
o
l d
b
la
c
k
(
p
a
in
t e d )
a
n
t
h
r a
c it e
s
ilv
e
r
A6
A4
A5
A3
A9
00
p
o
lis
h
e
d
b
r a s s
s
a
t
i
n
b
r a
s s
c
h
r
o
m
e
s
a
ti
n
c
h
r o
m e
A1
A2
A8
Lever handle will retract latch and deadbolt
simultaneously.
Thumbturn for withdrawal of deadbolt (standard
model only) and to activate privacy indicator (both
in standard and automatic deadbolt models).
Power supply: 24Vac 50Hz.
Max outside voltage: 24 Vac.
Outside power:
75 VA at start,
15 VA continuously.
Specs
Login and operation audit trail: 12,000 events.
Operators: 700 (card + password).
Active cards audit trail: 14,000.
Main power supply: 220Vac 50Hz (110Vac 60
Hz available on request).
Adjustable backlit display (2 columns per 40
lines).
Built in smart card reader.
Reader life:
200,000 cycles.
RS232 serial port for PMS interface.
Parallel port for printer. Network port.
ACCESS CONTROL
AUTONOMOUS NETWORK
RS485 like, up to 10 km.
Cable type: telecom, TR/R ATOX FLAM
(GEI 46,5).
2p (twisted) + G not shielded.
ENERGY SAVER
mylock
my
Main power supply: 220Vac 50Hz (110Vac 60Hz
available on request).
On board relay: NO/NC (120Vdc/240Vac-5A).
Programmable access time delay: from 0,01
sec. to 10 min.
Audit trail: 8,000 events (off-line configuration).
Black list: 1,000 cancelled cards.
60 auto-programme timetables available with 3 sta-
tes: normal, always on, lock-out (guest and/or staff).
Distance from smart reader (m): 20 max.
Smart readers per control unit: 2 max.
Power supply: 4 alkaline batteries AALR6 1,5 V
(supplied).
Batteries life:
30,000 cycles.
Audit trail: 500 events (mechanical override
included).
Black list: 80 cancelled cards.
Reader life:
100,000 cycles.
Operating temperature range: 0
-70
C.
RAM inside.
60 auto-programme timetables available with 3 sta-
tes: normal, always on, lock-out (guest and/or staff).
Login and operation audit trail: 2,100 events.
Operators: 250 (card + password).
Active cards audit trail: 2,400.
Main power supply: 220Vac 50Hz (110Vac 60Hz
available on request).
Alternate power supply: 4 alkaline batteries
AALR6 1,5 V (supplied).
Backlit display 6 columns per 16 lines.
Built in smart card reader.
Reader life:
200.000 cycles.
Buzzer (sounding key pad).
RS232 serial port for PMS interface or Smart
Reporting. Network port.
my
mobile
ELECTRONIC UNIT
INSIDE TRIM
ACCESS CONTROL UNIT
Latch and 16 or 25 mm (on request) deadbolt.
Panic release feature: latch and deadbolt retract
simultaneously.
Anti-friction latch and anti-theft piston.
Fire rating: 3 hours (finish INOX code 20).
Available back-set (mm): E = 60, 70, 80, 90.
Automatic deadbolt model on request.
ANSI model for USA markets available on request.
Strike plate on request.
EURO MORTISE LOCK
Weather proof.
2 LED displays (green and red).
Standard cable length (m): 5 (supplied).
Fixing screw supplied.
Distance from the control unit (m): 20 max.
Reader life:
200,000 cycles.
Operating temperature range 0
-70
C.
SMART READER
...my key
is only
denys access to card clones, reduces frauds and thefts;
communicates standard of quality and hotel security to guests;
can be used to supply other services to the guests;
uses a variety of smart cards (multiapplication) supplied by third parties and is able to offer more services simultaneously, as a
guest card;
allows faster and more user friendly card management and check-in operations;
is autonomous (no PC required) and virus free;
is easier to place on the reception desk, thanks to compact encoding systems;
is portable (
my
mobile
);
reduces installation and maintenance costs.
Benefits
is exclusively "my" card;
protects "my" belongings, safety and privacy;
can be simultaneously used for other services;
is user friendly.
To the guest:
To the hotel:
Are you aware that:
safety and security are guest's major requirements
when choosing hotels and destinations. (Source:
IH&RA 1999);
we are in a digital and cashless society. Travellers,
businessmen and tourists are more accustomed
to using the Internet to communicate - for
payments, reservations, etc. - and now appreciate
solutions that improve comfort, security and safety
during their stay;
today certain cards, easy to clone, are potential causes of thefts and frauds! Several
situations could arise where the hotel's business is at risk, i.e.:
- unattended card (fitness centre, swimming pool,...);
- cards called for POS payment;
- guests that are aware of clonable cards and hotel liability can defraud hotels by
making false claims of theft, demanding free accommodation or refunds.
Hotel business? Guest security!
mykey
security card: together with
mylock
,
my
and
my
mobile
encoding systems with 3DES cryptosystem on board, is the solution
to protect the hotel business: guests.
Durable elegance!
Special electrochemical treatment to withstand demanding environmental conditions.
A
nodized
Electrophoretic
with handle
with knob
Finishes
245
220
105
175
210
60
100
210
80
48
28
70
220
136
60
26
60
70
90
115
45
22
240
170
16
25
26
E
16
74
297
41
82
background image
mykey
security card
EXCLUSIVE.
An un-clonable card designed for the guest,
demonstrating the hotel's high standard of quality and security.
HIGHER VALUE.
Memory area to support other services provided
by third parties (hotel automation, credit and payment,
identification, loyalty schemes,...) is available on board.
MEDIA.
High quality personalization service of the reverse of
the card is available (maximum of 4 colours)!! Ask CISA for the
most suitable combination (colours/quantity) according to the
hotel promotion!
3DES engine
Finally it is possible to intercept and to deny access to card
clones (guest, staff,...) thanks to the authentication process.
Secured by secret key 3DES cryptosystem.
Developed by IBM in the middle 1970's and approved by USA
Federal Government. CISA 3DES engine is compliant with
NIST standards (National Institute of Standards and Technologies
USA).
INTEROPERABLE
Uses smart cards provided by third parties
(MULTIAPPLICATION)
as guest key cards.
mylock
is compatible with the most
widespread operating systems (MPCOS, JAVA, WINDOWS
FOR SMART CARD,...) and several smart cards are already
implemented.
AUDIT TRAIL
mylock
records the last 500 events, use of mechanical override
included. Without batteries, too!
AUTOMATIC WAKE-UP
Easy to manage the opening and the locking of fitness center,
conference rooms, business center and other common areas
according to programmable timetables. No staff assistance
required!
TSP MECHANICAL OVERRIDE
Means that the hotel security is not dependent on drills or other
manufacturers!
CISA manufactures both electronic and mechanical components.
Cylinder 3 times recodable with Side Bitting System (patented).
It avoids the need for recoding keys.
A series of 3 Master Keys (1, 2, 3) able to automatically recode
the cylinder in case of loss of the lowest levels, with special
TSP keyway (patented).
Security card: authorized key duplication by CISA and by its
presentation only.
4 BATTERIES ONLY
Powered for more than 3 years by 4 standard batteries only!!
This avoids "captive" proprietary battery packs, which are expensive
and not always available and 6 batteries supplied locks.
AUTOMATIC DEADBOLT
Antipanic lock with deadbolt that is automatically thrown when
door is closed for added security (on request).
ALL WEATHER
External model available for out door installation (on request).
Card clones are illegal!
mylock
, with 3DES cryptosystem on board, is the only lock that authenticates cards!
Only original cards are accepted.
mylock
:
the first lock powered with "3DES engine"!
MICROSOFT
Logical Access,
Internet, Information
Systems.
PHILIPS
Pay tv.
TELSTRA
Phone Charges.
PAYTRON
Payments.
AIRVENT
Hotel Automation,
Payments.
VISA
Financial Services.
..............
Smart cards provided by third parties, are able to support
several services simultaneously and can be used as guest
key cards thanks to
mylock
interoperability.
Summary follows:
MULTIAPPLICATION
Diagram
ENERGY SAVER: for guest comfort!
Simple and cost effective solution to reduce guestroom energy consumption. It is a card-operated switch
that can be placed at the entrance of the guest's room. Supplied with illuminated slot and delayed switch
off for guest comfort. Commercial transformers and contactors are available (on request).
Complementary elements
mykey
migration programme
With the programme designed to reward all CISA clients who have chosen 80100 Series, CS 9580 Magnetic, CS 9580 SMART
and SMART
Mobile locking systems, it is easy to migrate to
mykey
! Ask CISA which programme best suits your needs.
ACCESS CONTROL
Designed to manage the access to both restricted areas (parking, garage ...) and common areas (fitness
center, conference rooms, business center ...) according to programmable timetables. No staff assistance
required! Powered by
3DES
engine, card clones are kept out from the property thanks to the authentication
process! Weather proof reader. Can be installed where
mylock
could not fit with the existing frames, too.
Both off and on-line configurations are available. On-line configuration assures the real guest card invalidation
at check-out.
1
2
RS 232
RECEPTION
FITNESS CENTER
STAFF
301
302
303
304
305
201
202
203
204
205
101
102
103
104
105
3
n
1
BUSINESS CENTER
server
mirror/client
client
client
3
n
2
n
200
n
ENTRANCE
PMS
OFFICE
parking
AUTONOMOUS NETWORK
JOHNSON
CONTROLS
Building Automation.
background image
DUAL FUNCTION
my
mobile
is the portable unit able to carry out
two tasks:
- card issuing and management,
both stand-
alone and network configuration available;
- lock interrogation and programming.
USER FRIENDLY
Easy to manage and identify (audit trail) each
card by name, thanks to the user interface based
on mobile telephone standard (alphanumeric
keypad,...).
Encoding system
DUAL POWER SUPPLY
In addition to the mains power supply
my
mobile
is supplied with batteries which
guarantee its functioning even in case of
power failure.
SMART REPORTING
Software to make search, printing and
backup of the main files within a Windows
environment (on request).
FAST CHECK-IN
User interface specially designed for
receptionists. Allowing the issue of guest cards
in a few seconds even when not interfaced to
the PMS.
CUSTOMIZED STAFF CARDS
Each staff card can be customized to its unique
working area and timetable.
3DES engine
Finally it is possible to intercept and deny the
login to operator card clones, thanks to the
authentication process. Guaranteed by secret
key 3DES cryptosystem (see
mylock
).
AUTONOMOUS NETWORK
Multi-check-in stations facility without any
dedicated PC. Cards can be simultaneously
issued both by
my
/
my
mobile
and PMS even if
this is not active. The system architecture, based
on a shared database, allows it to manage up
to 200 devices in network:
my
,
my
mobile
and
on line access control units in mixed
configuration.
AUTONOMOUS, USER FRIENDLY AND ...
VIRUS FREE!
my
and
my
mobile
are autonomous, no PC
required therefore virus free. The system allows
check-in operations even when interfaced to the
PMS and this is not active.
PMS INTERFACE
Easily interfaceable to the most common PMS
without requiring extra devices or dedicated PC.
It is possible to operate simultaneously both from
the PMS and from the encoding system! When
connected,
my
and
my
mobile
become unique
smart readers/writers with built in display.
For hotel up to 300
rooms or perimeter
accesses properties.
For hotel up
to 2,400 rooms or
perimeter accesses
properties*.
The unique cost effective solution for those who want the benefits of the
most advanced, and by now, essential features.
HIGHER PERFORMANCES
For example: up to 2,400 access points, 12,000
login and events audit trail, 700 operators,
14,000 valid cards audit trail in memory!
BUILT IN PRINTER INTERFACE
my
permits files to be printed, thanks to a built
in parallel port.
my
+
my
mobile
= SUPERIOR FUNCTIONS
my
combined with
my
mobile
gives 2 (minimum)
check-in stations for card issuing and management,
in addition to the portable unit functions (lock
interrogation and programming).
NON STOP CHECK-IN
Fault tolerant configuration (server and mirror)
available for the maximum reliability and resilience
of check-in operations.
FEWER ELEMENTS, LESS WIRING, EASY TO
INSTALL ... COST EFFECTIVE
Equipped with built in smart card reader and
designed to avoid bulky communication units,
external smart or magnetic card reader/writers,
cables, dedicated software.
Small and compact it can be easily placed on
the reception desk.
EASIER TO INTERFACE
A dynamic link library and a development kit are
available for
my
and
my
mobile
system
integration or interface into Windows environment
(DLL 9800).
The encoding system achieves the highest performances
when combined with
my
mobile
.
* Configurations for hotels over 2,400 access points are available on request.
mobile
background image
DUAL FUNCTION
my
mobile
is the portable unit able to carry out
two tasks:
- card issuing and management,
both stand-
alone and network configuration available;
- lock interrogation and programming.
USER FRIENDLY
Easy to manage and identify (audit trail) each
card by name, thanks to the user interface based
on mobile telephone standard (alphanumeric
keypad,...).
Encoding system
DUAL POWER SUPPLY
In addition to the mains power supply
my
mobile
is supplied with batteries which
guarantee its functioning even in case of
power failure.
SMART REPORTING
Software to make search, printing and
backup of the main files within a Windows
environment (on request).
FAST CHECK-IN
User interface specially designed for
receptionists. Allowing the issue of guest cards
in a few seconds even when not interfaced to
the PMS.
CUSTOMIZED STAFF CARDS
Each staff card can be customized to its unique
working area and timetable.
3DES engine
Finally it is possible to intercept and deny the
login to operator card clones, thanks to the
authentication process. Guaranteed by secret
key 3DES cryptosystem (see
mylock
).
AUTONOMOUS NETWORK
Multi-check-in stations facility without any
dedicated PC. Cards can be simultaneously
issued both by
my
/
my
mobile
and PMS even if
this is not active. The system architecture, based
on a shared database, allows it to manage up
to 200 devices in network:
my
,
my
mobile
and
on line access control units in mixed
configuration.
AUTONOMOUS, USER FRIENDLY AND ...
VIRUS FREE!
my
and
my
mobile
are autonomous, no PC
required therefore virus free. The system allows
check-in operations even when interfaced to the
PMS and this is not active.
PMS INTERFACE
Easily interfaceable to the most common PMS
without requiring extra devices or dedicated PC.
It is possible to operate simultaneously both from
the PMS and from the encoding system! When
connected,
my
and
my
mobile
become unique
smart readers/writers with built in display.
For hotel up to 300
rooms or perimeter
accesses properties.
For hotel up
to 2,400 rooms or
perimeter accesses
properties*.
The unique cost effective solution for those who want the benefits of the
most advanced, and by now, essential features.
HIGHER PERFORMANCES
For example: up to 2,400 access points, 12,000
login and events audit trail, 700 operators,
14,000 valid cards audit trail in memory!
BUILT IN PRINTER INTERFACE
my
permits files to be printed, thanks to a built
in parallel port.
my
+
my
mobile
= SUPERIOR FUNCTIONS
my
combined with
my
mobile
gives 2 (minimum)
check-in stations for card issuing and management,
in addition to the portable unit functions (lock
interrogation and programming).
NON STOP CHECK-IN
Fault tolerant configuration (server and mirror)
available for the maximum reliability and resilience
of check-in operations.
FEWER ELEMENTS, LESS WIRING, EASY TO
INSTALL ... COST EFFECTIVE
Equipped with built in smart card reader and
designed to avoid bulky communication units,
external smart or magnetic card reader/writers,
cables, dedicated software.
Small and compact it can be easily placed on
the reception desk.
EASIER TO INTERFACE
A dynamic link library and a development kit are
available for
my
and
my
mobile
system
integration or interface into Windows environment
(DLL 9800).
The encoding system achieves the highest performances
when combined with
my
mobile
.
* Configurations for hotels over 2,400 access points are available on request.
mobile
background image
mykey
security card
EXCLUSIVE.
An un-clonable card designed for the guest,
demonstrating the hotel's high standard of quality and security.
HIGHER VALUE.
Memory area to support other services provided
by third parties (hotel automation, credit and payment,
identification, loyalty schemes,...) is available on board.
MEDIA.
High quality personalization service of the reverse of
the card is available (maximum of 4 colours)!! Ask CISA for the
most suitable combination (colours/quantity) according to the
hotel promotion!
3DES engine
Finally it is possible to intercept and to deny access to card
clones (guest, staff,...) thanks to the authentication process.
Secured by secret key 3DES cryptosystem.
Developed by IBM in the middle 1970's and approved by USA
Federal Government. CISA 3DES engine is compliant with
NIST standards (National Institute of Standards and Technologies
USA).
INTEROPERABLE
Uses smart cards provided by third parties
(MULTIAPPLICATION)
as guest key cards.
mylock
is compatible with the most
widespread operating systems (MPCOS, JAVA, WINDOWS
FOR SMART CARD,...) and several smart cards are already
implemented.
AUDIT TRAIL
mylock
records the last 500 events, use of mechanical override
included. Without batteries, too!
AUTOMATIC WAKE-UP
Easy to manage the opening and the locking of fitness center,
conference rooms, business center and other common areas
according to programmable timetables. No staff assistance
required!
TSP MECHANICAL OVERRIDE
Means that the hotel security is not dependent on drills or other
manufacturers!
CISA manufactures both electronic and mechanical components.
Cylinder 3 times recodable with Side Bitting System (patented).
It avoids the need for recoding keys.
A series of 3 Master Keys (1, 2, 3) able to automatically recode
the cylinder in case of loss of the lowest levels, with special
TSP keyway (patented).
Security card: authorized key duplication by CISA and by its
presentation only.
4 BATTERIES ONLY
Powered for more than 3 years by 4 standard batteries only!!
This avoids "captive" proprietary battery packs, which are expensive
and not always available and 6 batteries supplied locks.
AUTOMATIC DEADBOLT
Antipanic lock with deadbolt that is automatically thrown when
door is closed for added security (on request).
ALL WEATHER
External model available for out door installation (on request).
Card clones are illegal!
mylock
, with 3DES cryptosystem on board, is the only lock that authenticates cards!
Only original cards are accepted.
mylock
:
the first lock powered with "3DES engine"!
MICROSOFT
Logical Access,
Internet, Information
Systems.
PHILIPS
Pay tv.
TELSTRA
Phone Charges.
PAYTRON
Payments.
AIRVENT
Hotel Automation,
Payments.
VISA
Financial Services.
..............
Smart cards provided by third parties, are able to support
several services simultaneously and can be used as guest
key cards thanks to
mylock
interoperability.
Summary follows:
MULTIAPPLICATION
Diagram
ENERGY SAVER: for guest comfort!
Simple and cost effective solution to reduce guestroom energy consumption. It is a card-operated switch
that can be placed at the entrance of the guest's room. Supplied with illuminated slot and delayed switch
off for guest comfort. Commercial transformers and contactors are available (on request).
Complementary elements
mykey
migration programme
With the programme designed to reward all CISA clients who have chosen 80100 Series, CS 9580 Magnetic, CS 9580 SMART
and SMART
Mobile locking systems, it is easy to migrate to
mykey
! Ask CISA which programme best suits your needs.
ACCESS CONTROL
Designed to manage the access to both restricted areas (parking, garage ...) and common areas (fitness
center, conference rooms, business center ...) according to programmable timetables. No staff assistance
required! Powered by
3DES
engine, card clones are kept out from the property thanks to the authentication
process! Weather proof reader. Can be installed where
mylock
could not fit with the existing frames, too.
Both off and on-line configurations are available. On-line configuration assures the real guest card invalidation
at check-out.
1
2
RS 232
RECEPTION
FITNESS CENTER
STAFF
301
302
303
304
305
201
202
203
204
205
101
102
103
104
105
3
n
1
BUSINESS CENTER
server
mirror/client
client
client
3
n
2
n
200
n
ENTRANCE
PMS
OFFICE
parking
AUTONOMOUS NETWORK
JOHNSON
CONTROLS
Building Automation.
background image
b
r
o
n
z e
g
o
l d
b
la
c
k
(
p
a
in
t e d )
a
n
t
h
r a
c it e
s
ilv
e
r
A6
A4
A5
A3
A9
00
p
o
lis
h
e
d
b
r a s s
s
a
t
i
n
b
r a
s s
c
h
r
o
m
e
s
a
ti
n
c
h
r o
m e
A1
A2
A8
Lever handle will retract latch and deadbolt
simultaneously.
Thumbturn for withdrawal of deadbolt (standard
model only) and to activate privacy indicator (both
in standard and automatic deadbolt models).
Power supply: 24Vac 50Hz.
Max outside voltage: 24 Vac.
Outside power:
75 VA at start,
15 VA continuously.
Specs
Login and operation audit trail: 12,000 events.
Operators: 700 (card + password).
Active cards audit trail: 14,000.
Main power supply: 220Vac 50Hz (110Vac 60
Hz available on request).
Adjustable backlit display (2 columns per 40
lines).
Built in smart card reader.
Reader life:
200,000 cycles.
RS232 serial port for PMS interface.
Parallel port for printer. Network port.
ACCESS CONTROL
AUTONOMOUS NETWORK
RS485 like, up to 10 km.
Cable type: telecom, TR/R ATOX FLAM
(GEI 46,5).
2p (twisted) + G not shielded.
ENERGY SAVER
mylock
my
Main power supply: 220Vac 50Hz (110Vac 60Hz
available on request).
On board relay: NO/NC (120Vdc/240Vac-5A).
Programmable access time delay: from 0,01
sec. to 10 min.
Audit trail: 8,000 events (off-line configuration).
Black list: 1,000 cancelled cards.
60 auto-programme timetables available with 3 sta-
tes: normal, always on, lock-out (guest and/or staff).
Distance from smart reader (m): 20 max.
Smart readers per control unit: 2 max.
Power supply: 4 alkaline batteries AALR6 1,5 V
(supplied).
Batteries life:
30,000 cycles.
Audit trail: 500 events (mechanical override
included).
Black list: 80 cancelled cards.
Reader life:
100,000 cycles.
Operating temperature range: 0
-70
C.
RAM inside.
60 auto-programme timetables available with 3 sta-
tes: normal, always on, lock-out (guest and/or staff).
Login and operation audit trail: 2,100 events.
Operators: 250 (card + password).
Active cards audit trail: 2,400.
Main power supply: 220Vac 50Hz (110Vac 60Hz
available on request).
Alternate power supply: 4 alkaline batteries
AALR6 1,5 V (supplied).
Backlit display 6 columns per 16 lines.
Built in smart card reader.
Reader life:
200.000 cycles.
Buzzer (sounding key pad).
RS232 serial port for PMS interface or Smart
Reporting. Network port.
my
mobile
ELECTRONIC UNIT
INSIDE TRIM
ACCESS CONTROL UNIT
Latch and 16 or 25 mm (on request) deadbolt.
Panic release feature: latch and deadbolt retract
simultaneously.
Anti-friction latch and anti-theft piston.
Fire rating: 3 hours (finish INOX code 20).
Available back-set (mm): E = 60, 70, 80, 90.
Automatic deadbolt model on request.
ANSI model for USA markets available on request.
Strike plate on request.
EURO MORTISE LOCK
Weather proof.
2 LED displays (green and red).
Standard cable length (m): 5 (supplied).
Fixing screw supplied.
Distance from the control unit (m): 20 max.
Reader life:
200,000 cycles.
Operating temperature range 0
-70
C.
SMART READER
...my key
is only
denys access to card clones, reduces frauds and thefts;
communicates standard of quality and hotel security to guests;
can be used to supply other services to the guests;
uses a variety of smart cards (multiapplication) supplied by third parties and is able to offer more services simultaneously, as a
guest card;
allows faster and more user friendly card management and check-in operations;
is autonomous (no PC required) and virus free;
is easier to place on the reception desk, thanks to compact encoding systems;
is portable (
my
mobile
);
reduces installation and maintenance costs.
Benefits
is exclusively "my" card;
protects "my" belongings, safety and privacy;
can be simultaneously used for other services;
is user friendly.
To the guest:
To the hotel:
Are you aware that:
safety and security are guest's major requirements
when choosing hotels and destinations. (Source:
IH&RA 1999);
we are in a digital and cashless society. Travellers,
businessmen and tourists are more accustomed
to using the Internet to communicate - for
payments, reservations, etc. - and now appreciate
solutions that improve comfort, security and safety
during their stay;
today certain cards, easy to clone, are potential causes of thefts and frauds! Several
situations could arise where the hotel's business is at risk, i.e.:
- unattended card (fitness centre, swimming pool,...);
- cards called for POS payment;
- guests that are aware of clonable cards and hotel liability can defraud hotels by
making false claims of theft, demanding free accommodation or refunds.
Hotel business? Guest security!
mykey
security card: together with
mylock
,
my
and
my
mobile
encoding systems with 3DES cryptosystem on board, is the solution
to protect the hotel business: guests.
Durable elegance!
Special electrochemical treatment to withstand demanding environmental conditions.
A
nodized
Electrophoretic
with handle
with knob
Finishes
245
220
105
175
210
60
100
210
80
48
28
70
220
136
60
26
60
70
90
115
45
22
240
170
16
25
26
E
16
74
297
41
82
background image
PDE132
ahd@cisanet.com
www.cisa.com
